Why Choose Aeronergic for PW530 Series Inspections
- 1
EASA PART 145 Certified with EASA Form 1
Our inspections are performed to the highest regulatory standards under our EASA Part 145 approval (EE.145.0124). We issue an EASA Form 1, providing the certified documentation you need for your maintenance records and asset transitions.
- 2
24/7 Worldwide AOG Support
An aircraft on the ground is a critical liability. Our expert teams are strategically positioned globally and ready to deploy 24/7, ensuring a rapid response to your AOG situation anywhere in the world to minimize downtime.
- 3
Advanced 3D Measurement Technology
We use the latest videoscope technology featuring high-resolution imaging and 3D measurement. This allows us to move beyond subjective visual checks to provide precise, objective data on any findings, empowering you to make confident maintenance and financial decisions.
- 4
Unmatched Technical Expertise
Our inspectors possess deep, platform-specific knowledge of the PW530 architecture and common failure modes. We deliver detailed digital reports that provide a clear, actionable assessment of your engine's condition.
Service Overview
Aeronergic provides EASA Part 145 on-wing borescope inspections for the Pratt & Whitney Canada PW530 powering aircraft such as the Citation Bravo. Our teams deliver rapid 24–48 hour turnaround and 24/7 AOG response, issuing an EASA Form 1 on completion. Inspections use high-resolution videoscopes with 3D measurement and result in a clear digital report with annotated photos/video and OEM-referenced acceptance criteria. PW530 inspections target the engine’s known drivers of performance and reliability: HP compressor (IGVs and stages, with particular focus on the 2nd-stage HP rotor for nicks, tip rub, and FOD), reverse-flow combustor (outer liner cooling ring integrity, burn-through, hot spots), and the hot section (HPT/LPT blades and vanes for cracks, coating loss, oxidation, and tip erosion). We also check for carbon/oil deposits in accessible bearing cavities. Findings are quantified, trended, and tied to AMM limits with clear recommendations—return-to-service, re-inspect at the next interval, or maintenance action—minimizing downtime and protecting asset value.
Technical Specifications
| Thrust Range | 2,887 lbf (12.8 kN) |
| Bypass Ratio | 3.7:1 |
| Fan Diameter | 23 in (58.4 cm) |
| Compressor Stages | 1 fan, 3 HP (2 axial + 1 centrifugal) |
| Turbine Stages | 1 HPT, 2 LPT |
Supported PW530 Series Models
- PW530A
- PW535A
- PW535B
- PW535E
- PW535E1
Please contact us to discuss your specific maintenance requirements or to request a service quote.
Our team is ready to provide expert support wherever your aircraft operate.
